ASTO 308

A 3 mm²/s synthetic ester oil with additives targeted at oxidation and corrosion resistance, and wear reduction. It offers dependability for older engines that require a MIL-PRF-7808 oil.

Specifications & approvals

Country Specification
United States MIL-PRF-7808M Grade 3
NATO Code O-148
Joint Service Designation OX-9



Download TDS (PDF)
Download MSDS (UK)

The TDS and MSDS are in English, but you can find these documents for other countries in the Shell EPC area
.

Applications

AeroShell Turbine Oil 308 was developed specifically for use in particular models of aircraft prop and turbojet engines for which a MIL-PRF-7808 (formerly MIL-L-7808) oil is required.

AeroShell Turbine Oil 308 contains a synthetic ester oil and should not be used in contact with incompatible seal, and it also affects some paints and plastics.

  • Health, Safety and Environment

    Health and Safety

    • This product is unlikely to present any significant health or safety hazard when properly used in the recommended application and good standards of personal hygiene are maintained.
    • Avoid contact with skin. Use impervious gloves with used oil. After skin contact, wash immediately with soap and water.
    • Guidance on Health and Safety is available on the appropriate Safety Data Sheet, which can be obtained from https://www.epc.shell.com/

    Protect the Environment

    • Take used oil to an authorised collection point. Do not discharge into drains, soil or water.

Additional information

Advice

  • Advice on applications not covered here may be obtained from your Shell representative.

Get in touch with us

We’re here to assist you with any inquiries or support you may need

Contact Us

Typical Physical Characteristics

Properties Method MIL-PRF-7808M Grade 3 Typical
Oil type – Synthetic ester Synthetic ester
Kinematic Viscosity @100°C mm²/s ASTM D445 3.0 min 3.1
Kinematic Viscosity @40°C mm²/s ASTM D445 11.5 min 12
Kinematic Viscosity @-51°C mm²/s ASTM D2532 13 000 max 7 600
Flash Point °C ASTM D92 210 min 225
Total Acidity mgKOH/g ASTM D664 0.40 max 0.27
Trace metal content – Must pass Passes
Foaming tendency ASTM D892 Must pass Passes
Evaporation loss (6.5 hrs) @205°C %m ASTM D972 30 max 28
Corrosion test – Silver @232°C g/m² FED-STD-791 M.5305 +/- 4.5 max 0.01
Corrosion test – Bronze @232°C g/m² FED-STD-791 M.5305 +/- 4.5 max 0.09
Deposition Test WADC – deposit rating FED-STD-791 M.5003 1.5 max 0.8
Deposition Test WADC – acid number change, % FED-STD-791 M.5003 20 max 2
Deposition Test WADC – viscosity change @40°C, % FED-STD-791 M.5003 100 max 12
Elastomer compatibility SAE AMS 3217/1, 168 hrs @70°C, % swell FED-STD-791 M.3604 12 to 35 32
Elastomer compatibility SAE AMS 3217/4, 72 hrs @175°C, % swell FED-STD-791 M.3432 2 to 25 16
Elastomer compatibility SAE AMS 3217/4, 72 hrs, tensile strength change @175°C, % FED-STD-791 M.3432 50 max -18
Elastomer compatibility SAE AMS 3217/4, 72 hrs, elongation change @175°C, % FED-STD-791 M.3432 50 max -16
Elastomer compatibility SAE AMS 3217/4, 72 hrs, hardness change @175°C, % FED-STD-791 M.3432 20 max -8
Elastomer compatibility SAE AMS 3217/5, 72 hrs @150°C, % swell FED-STD-791 M.3432 2 to 25 9
Elastomer compatibility SAE AMS 3217/5, 72 hrs, tensile strength change @150°C, % FED-STD-791 M.3432 50 max -9
Elastomer compatibility SAE AMS 3217/5, 72 hrs, elongation change @150°C, % FED-STD-791 M.3432 50 max -27
Elastomer compatibility SAE AMS 3217/5, 72 hrs, hardness change @150°C, % FED-STD-791 M.3432 20 max -5
Lead Corrosion FED-STD-791 M.5321 9.3 max 0.2
Corrosion and Oxidation Stability 96h @ 200°C ASTM D4636 Must pass Passes
Gravimetric particulate contamination FED-STD-791 M.3013 Must pass Passes
Gear load carrying capacity FED-STD-791 FTM 6508 Must pass Passes



These characteristics are typical of current production. Whilst future production will conform to Shell’s specification, variations in these characteristics may occur.
